Description
Specification
| Processor | Cortex-M3 |
| Basic Frequency | 96MHz |
| Flash | 2MB |
| SDRAM | 128KB |
| Operating System | FreeRTOS |
| Ethernet | |
| Interface Standard | 2 RJ45 with LED |
| Rate | 10/100 Base-T Auto-Negotiation |
| Protection | 2KV Isolation |
| Network Protocol | IP，TCP，UDP，DHCP，DNS，HTTP Server/Client，ARP，BOOTP，AutoIP， ICMP，Web socket，Telnet，FTP，TFTP，uPNP，NTP，Modbus TCP |
| Security Protocol | TLS v1.2 AES 128Bit DES3 |
| Wi-Fi Security | |
| Port Number | 4 |
| Interface Standard | RS232：DB9， RS485：2 wire（A+，B-）， RS422：4 wire（T+，T-，R+，R-） |
| Data Bits | 5，6，7，8 |
| Stop Bit | 1，2 |
| Check Bit | None，Even，Odd |
| Baud Rate | TTL：1200 bps~460800 bps |
| Flow Control | No Flow control Hardware RTS/CTS、DSR/DTR Software Xon/ Xoff flow control |
| Buffer | 4K |
| Configuration | Http Web Configuration Web CLI XML import Telnet IOTManagerPC Software |
| Virtual Serial | Windows, XP/Vista, 7， 8，10 Server 2003/2008/2012 |
| Size | 197x 165x25mm |
| Operating Temp. | -40 ~ 85°C |
| Storage Temp. | -45 ~ 105°C，5 ~ 95% RH（no condensation） |
| Input Voltage | 9~48VDC |
| Working Current | ~400mA |
| Power | <4W |
| Warranty | 1 year |
| Accessory | 1* 5V/1A Power Supply 1*Ethernet Cable |
